Shrink Tubing I.D. Before Shrinking
0.35 in
Shrink Tubing Material
Polyolefin
I.D. After Shrinking
0.12 in
Shrink Tubing Type
Heat Shrink Tubing
Shrink Tubing Wall Type
Heavy Wall
Shrink Tubing Usable Temp. Range
-67 Degrees to 230 Degrees F
Shrink Tubing Adhesive Lined
Yes
Use Shrink Tubing With Wire Size
14 to 10 AWG
Standards
CSA 22.2, UL 224, 120 Degrees C
Shrink Tubing Wall Thickness After Shrinking
0.07 in
Min. Shrink Temp.
248 Degrees F
I.D. Before Shrinking
0.35 in
Temp. Range
-67 Degrees to 230 Degrees F
Tubing Wall Type
Heavy Wall
Use With Wire Size
14 AWG to 10 AWG
Min. Temp. Rating
-67 Degrees F
Shrink Tubing Properties
High Heat Resistant
Package Style
Individual Pieces
Wall Thickness After Shrinking
0.07 in
Material
Cross-Linked Polyolefin with Adhesive
Max. Temp. Rating
230 Degrees F
Length (Straight Wireway)
4 ft
Minimum Expanded I.D. (inches)
0.35
Temperature Range
-55°C - 110°C
Fits AL/CU Splice with Max. Length
1
Maximum Recovered I.D. (inches)
0.12
Standard Length (inches)
48
Nominal Recovered Wall (inches)
0.07
Special Features
Made of thermally stabilized cross-linked polyolefin, enabling a recovered wall thickenss greater than that of the cable jacket replaced.
Nominal diameter inch
3/8 inch
Operation temperature
-67-+230 °F
Inner diameter before heat-shrink
0.35 inch
Type
Heavy-Wall Heat Shrinkable Tubing
Inner diameter after heat-shrink
0.12 inch
Country of Origin (subject to change)
United States
