Promotion Restriction
Not eligible for promotion
Current Measurement Range
0 to 1A AC/DC
Voltage Measurement Range
0 to 1000V AC/DC
Loop Supply Voltage
24 V DC
Accuracy
+/-0.05% + 2 Digits
Measurement Functions
Continuity Check, Current, Diode Test, Frequency, Resistance, Voltage
Basic DC Accuracy
0.2% + 2 LSD (DC)
Manufacturers Warranty Length
3 yr
Calibration Certificate
No
Includes
Alligator Clips, Test Leads
Source/Simulate
Current Source
Standards
CE, CSA, EMC EN 61326-1:2006, FCC: T68-FBLE IC: 6627A-FBLE, IEC 61010-1
Number of Batteries Required
4
CAT Safety Rating
CAT III 1000V, CAT IV 600V
Source Current - Minimum
0 mA
Calibration Certificate Type
Not Certified
Parameters Measured
AC Current, AC Voltage, Continuity, DC Current, DC Voltage, Diode, Frequency
Frequency Measurement - Maximum
19.999 kHz
Communication Protocol
HART
Parameters Sourced
DC Current, Resistance
Current Measurement - Maximum
30 mA
Loop Current - Maximum
20 mA
Intrinsic Safety
Not Specified Intrinsically Safe
Voltage Measurement - Maximum
1,000 V AC/DC
Battery Chemistry
Alkaline
AC Magnitude Calculation
True RMS
Resistance Measurement - Maximum
40 megaohm
Current Measurement - Minimum
0 mA
Frequency Measurement - Minimum
0.5 Hz
Includes Batteries
Batteries Included
Source Current - Maximum
20 mA
Voltage Measurement - Minimum
0 V AC/DC
Digital Display Screen Type
LCD with Backlight
Country of Origin (subject to change)
United States
