Switch Action
Close on Rise, Open on Rise
Differential
1 Degrees to 30 Degrees F
Full Load Amps @ 240VAC
8 A
Control Range
-40 Degrees to 212 Degrees F
For Use With
Suitable for Temperature Control in Heating, Cooling Applications
Standards
CE, Class B Industry Canada (IC) Compliant to Canadian ICES-003, cULus, FCC CFR47, UL 60730 File E27734, Vol. 1
Features
Removable Sensor with Screw Terminals and 6-1/2 ft Lead, Keypad Lock Out, Sensor Failure, Adjustable Anti Short Cycle Delay
Includes
A99BB-200C Temperature Sensor
Thermostat Switch Type
SPDT
Full Load Amps @ 120VAC
16 A
Display Size
1.5 x .5 sq in
Agency Compliance
C-UL listed, UL
Contact Rating Resistive @ 120V
15A
Contact Rating Resistive @ 277V
10A
Contact Rating Resistive @ 240V
10A
Input Voltage
120V AC, 240V AC
Application
Boiler Control, Chiller Control, Fan Control, Cooling Control, Temperature Sensing and Control, Heating Control, Damper Control
Product Type
Temperature Control
Resistive Load Current @ 120V
96 A
Variable Output Voltage
No
Compatible with Series
A99
Number of Sensors Included
1
Ambient Humidity
0% to 95% RH
Resistive Load Current @ 240V
48 A
Maximum Temperature Differential Setting
30 Degrees F
Maximum Control Temperature
212 Degrees F
Minimum Control Temperature
-40 Degrees F
Sensing Bulb Diameter
1/4 in
Temperature Control Function
Heat and Cool
Full Load Current @ 120V AC
16 A
Full Load Current @ 240V AC
8 A
Minimum Temperature Differential Setting
1 Degrees F
Country of Origin (subject to change)
Mexico
